Product Details
Place of Origin: China
Brand Name: xinhe
Certification: Rohs & Reach Certificate
Model Number: LQ-40
Payment & Shipping Terms
Minimum Order Quantity: 100 pcs
Price: Negotiable
Packaging Details: carton package
Delivery Time: Normally 3-5 working days
Payment Terms: T/T, L/C, Western Union
Material: |
Tungsten Carbide Steel |
Outer Diameter: |
40 Mm |
Inner Diameter: |
15 Mm |
Width: |
22 Mm Or 11mm Thickness |
N.W: |
0.128 KG |
Carbide Tip Dimension: |
2*6*21.5 Mm |
Use: |
Asphalt Surface |
Color Or Coating: |
Silver Zinc/ Blackned/bronze Coating |
Material: |
Tungsten Carbide Steel |
Outer Diameter: |
40 Mm |
Inner Diameter: |
15 Mm |
Width: |
22 Mm Or 11mm Thickness |
N.W: |
0.128 KG |
Carbide Tip Dimension: |
2*6*21.5 Mm |
Use: |
Asphalt Surface |
Color Or Coating: |
Silver Zinc/ Blackned/bronze Coating |
Bartell 8" Electric Concrete Scarifier Bef200n Accessories Drum Replacement, Tct Milling Cutters & Washers
Specification:
Milling Scarifier Cutters hard metal cutter with tungsten carbide tips for scarifying an milling accessories
5 edge tungsten carbide milling cutter
O.D. 40mm x I.D. 15mm x Width 22mm
O.D. 1.57" I.D. 0.59" Width 0.87"
carbide fully hardened steel body
Long Lasting Tungsten Carbide Tips
Finish: Zinc place coating or blackened treatment
Application:
Scarifier Milling Cutters are used to smooth the surface of a material that is soft or thick, such as epoxy. These cutters leave the surface smooth for further preparation and are often used following a carbide-tipped cutter. The Scarifier Milling Cutter can be utilized when the bulk of material needs to be removed from your surfaces before applying adhesives, mastic, or epoxy; this ensures that your final product will have a smooth looking finish.
| Products Lists | |||||||
| ITEM | DESCRITION | SPEC. | |||||
| Tip Number | O. D | I. D | Width | Carbide Tip Dimension | N.W. | ||
| TCT Carbide Flail cutters | |||||||
| Y1005 | 5pt TCT Flail Carbide Cutter | 5 | 43 mm | 16 mm | 6 mm | 4*8.5 mm | 0.038kg |
| Y1006 | 6pt TCT Flail Carbide Cutter | 6 | 47 mm | 15.5 mm | 6 mm | 4*8.5 mm | 0.048kg |
| 6 | 47 mm | 17mm | 6 mm | 4*8.5 mm | 0.047kg | ||
| 6 | 47 mm | 20 mm | 6 mm | 4*8.5 mm | 0.041kg | ||
| Y1006-1 | 6pt TCT Flail Carbide Cutter | 6 | 56.9 mm | 17.3 mm | 6 mm | 4*8.5 mm | 0.083kg |
| 6 | 56.9 mm | 25 mm | 6 mm | 4*8.5 mm | 0.071kg | ||
| Y1008F | 8pt TCT Flail Carbide Cutter | 8 | 58.3 mm | 17.6 mm | 6 mm | 4*8.5 mm | 0.075kg |
| Y1008B | 8pt TCT Flail Carbide Cutter | 8 | 60.3 mm | 20 mm | 6 mm | 4*8.5 mm | 0.085kg |
| 8 | 60.3 mm | 18 mm | 6 mm | 4*8.5 mm | 0.081kg | ||
| 8 | 60.3 mm | 22 mm | 6 mm | 4*8.5 mm | 0.079kg | ||
| 8 | 60.3 mm | 25.8 mm | 6 mm | 4*8.5 mm | 0.074kg | ||
| Y1008D | 8pt TCT Flail Carbide Cutter | 8 | 82.5 mm | 30 mm | 8 mm | 4*8.5 mm | 0.217kg |
| Y1012A | 12pt TCT Flail Carbide Cutter | 12 | 80 mm | 26 mm | 8 mm | 4*8.5 mm | 0.224kg |
| Y1012B | 12pt TCT Flail Carbide Cutter | 12 | 80 mm | 30 mm | 8 mm | 4*8.5 mm | 0.224kg |
| Full Face Carbide Cutters-- Wide Teeth | |||||||
| F2006 | 6pt Full Face Carbide Cutter | 6 | 47 mm | 15.5 mm | 6 mm | 6*6*3 mm | 0.048kg |
| F2008 | 8pt Full Face Carbide Cutter | 8 | 60.3 mm | 20 mm | 6 mm | 6*6*3 mm | 0.087kg |
| F2016 | 12pt Full Face Carbide Cutter | 16 | 82 mm | 26.5 mm | 8 mm | 10*8*3 mm | 0.285kg |
| Milling cutters | |||||||
| LQ-80 | 6pt Carbide Milling Cutter | 6 | 80 mm | 30 mm | 19 mm | 3*11*19 mm | 0.482kg |
| LQ-55 | 6pt Carbide Milling Cutter | 6 | 55 mm | 18 mm | 19 mm | 3*7*18.5mm | 0.251kg |
| LQ-60 | 6pt Carbide Milling Cutter | 6 | 60 mm | 25 mm | 19 mm | 2*6*21.5mm | 0.35kg |
| LQ-40 | 5pt Carbide Milling Cutter | 5 | 40 mm | 15 mm | 22 mm | 2*6*21.5mm | 0.138kg |
| Full Hardened Steel Cutters | |||||||
| QG-C | 12pt Hardened Beam Steel Cutter-blunt tip | 12 | 41.9 mm | 16.2 mm | 3.1mm | N/A | 0.015kg |
| QG-B | 18pt Hardened Star Steel Cutter-sharp tip | 18 | 31 mm | 7 mm | 2.5 mm | N/A | 0.012kg |
